O8851 Overhead Line Insulation Sleeve(1-35kV)

Applications:
Supply insulation and protecting for overhead line core cables，prevent short circuit accidents caused by incidental contact of tree branches or wildlife.
Also used for railway contact network overhead line system, improve insulation performance to ensure the safe operation of railway line.
Features:
Anti-tracking
UV resistance, and abrasion resistance
Easy installation with hand tool
Operating temperature: -40℃to 80℃
Standard color: red (black, green and yellow are available on request)
Dimensions:
Size   Suitable Suitable conductor section   Max.conductor   diameter
Φ20            1-35kV                                              185 mm2     22mm
Φ28            1-35kV                                              240 mm2     30mm
*Other sizes and packing are available on requested.
